Double Suction Centrifugal Pump Supplier
providing horizontal split case pumps for municipal water supply, industrial water transfer,
irrigation and cooling systems. Customized materials, drives and pump configurations are available.
Description
Technical Parameters
Henan Yibeng Pump Industry Co., Ltd. is one of the leading manufacturers and suppliers of double suction centrifugal pump supplier in China. We have world-leading production equipment and strong manufacturing capabilities. Please rest assured to buy durable double suction centrifugal pump supplier at competitive price from our factory.
Double Suction Centrifugal Pump Supplier
HNYB is a professional double suction centrifugal pump supplier and manufacturer in China, offering horizontal split-case pumps suitable for municipal water supply, industrial water transport, irrigation, cooling water circulation, and other high-flow applications.
Our pumps feature a double-suction impeller and an axially split casing. The double-suction hydraulic arrangement allows liquid to enter the impeller from both sides, while the split casing provides access to internal rotating components for inspection and maintenance.
Pump capacity, head, materials, sealing arrangements and drive configurations are selected according to the required duty point and project conditions. Electric motor and diesel engine driven configurations can be considered according to the selected model.
Why Choose Our Double Suction Centrifugal Pumps
High flow capacity for large-scale water systems
Double suction impeller design reduces axial force
Stable operation with low vibration and noise
High efficiency hydraulic model design
Easy maintenance with horizontal split case structure
Long service life for continuous operation
Technical Specifications
| Item | Range |
|---|---|
| Flow Rate | 50 – 18000 m³/h |
| Head | 10 – 260 m |
| Power | 11 – 2240 kW |
| Outlet Diameter | DN80 – DN1200 |
| Speed | 740 / 990 / 1480 / 2960 RPM |
| Pressure | Up to 2.6 MPa |
| Temperature | -20°C to 150°C |
Products Video
Application Scenario:
Municipal Water Utilities: Main water intake stations, large-scale clean water distribution networks, and regional water supply pumping plants.
Power & Energy Infrastructure: Main cooling water circulation loops for thermal and nuclear power plants, as well as general industrial boosting.
Mining & Industrial Dewatering: Reliable handling of massive volumes of surface runoff water, mine pit drainage, and flood control mitigation.
Metallurgy & Iron/Steel Mills: High-pressure, high-volume cooling water loops for blast furnaces, rolling mills, and processing utilities.
Advantages of Double Suction Centrifugal Pumps
Higher Flow Capacity
The double-entry impeller design allows significantly larger flow rates than conventional centrifugal pumps.
Reduced Axial Thrust
Liquid enters from both sides of the impeller, balancing hydraulic forces and extending bearing life.
High Efficiency
Optimized hydraulic passages improve efficiency and reduce energy consumption.
Low Vibration
Balanced rotor design ensures stable operation even under continuous-duty conditions.
Easy Maintenance
The split casing design allows inspection and servicing without removing suction and discharge piping.
Long Service Life
Heavy-duty construction ensures reliable performance in demanding industrial applications.
Product Features
Double Suction Impeller Design
Balanced hydraulic forces reduce bearing load and improve stability.
Horizontal Split Case Structure
Allows easy maintenance without removing piping or motor.
High Efficiency Operation
Optimized impeller and casing design ensures energy savings.
Heavy Duty Construction
Suitable for continuous industrial and municipal applications.
Why Choose HNYB as Your Double Suction Pump Supplier
Integrated Manufacturing Capabilities
HNYB operates manufacturing facilities covering casting, heat treatment, machining, pump assembly, coating and testing. These capabilities support process control across multiple stages of pump production.
Pump Configuration for Project Requirements
Pump selection can be based on the required flow rate, total head, liquid properties, materials, operating temperature and installation conditions. Different hydraulic and drive configurations should be evaluated against the actual duty point.
Material and Drive Options
Depending on the selected pump series, available configurations may include cast iron, ductile iron, cast steel or stainless steel components, together with electric motor or diesel engine drives.
Technical Selection Support
Providing the operating duty point and site conditions helps the HNYB team identify an appropriate pump model, review the hydraulic requirements and assess the necessary materials and drive configuration.
Quality Inspection and Testing
Pump inspection and testing arrangements can be confirmed for the selected order. Customers should specify any required test scope, inspection records, material documentation or project-specific quality requirements before production.
OEM and Customized Manufacturing
Where technically feasible, pump dimensions, materials, seals, connections and drive arrangements can be discussed according to the project specification and confirmed manufacturing capabilities.
Product Certification
ISO 9001
ISO14001
ISO45001
CE Product Certification
EAC Product Certification
Verified Supplier
Our address
Zhaogang Industrial Park, Fengqiu, Xinxiang, Henan, China
WhatsApp Number
+86 158 3619 1545
sales@hnybpumps.com
FAQ
Q: What is a double suction centrifugal pump?
A: It is a high flow centrifugal pump with a double suction impeller designed to balance axial forces and improve efficiency.
Q: What is it used for?
A: It is widely used in municipal water supply, irrigation, industrial water transfer and pumping stations.
Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer of industrial water pumps in China.
Q: Can you customize the pump?
A: Yes, we provide customized flow, head, material and drive options.
Q: What materials are available?
A: Cast iron, ductile iron, stainless steel and cast steel are available.
Hot Tags: double suction centrifugal pump supplier, China double suction centrifugal pump supplier manufacturers, Double Suction Axial Split Case Pump, High Pressure Axially Split Pump, Irrigation Axially Split Pump, Sewage Axially Split Pump, Single Stage Horizontal Split Case Centrifugal Pump, Vertical Axially Split Pump
| Flow(Q): | 50-18000m³/ H |
| Head(H): | 10-260m |
| Pressure: | 0.1MPa-2.6MPa(1Bar-26Bar) |
| Caliber: | ≤1200mm |
| Power: | 11-2240kw |
| Medium temperature: | -20℃-150℃(-4°F-482°F)(above 80 ℃, please specify) |
| Material: | Cast iron/ductile iron/cast steel/stainless steel, etc |
| Application scope: | The S-type double suction split pump is a horizontal single pole double suction horizontal split centrifugal pump developed by our factory. It is an efficient and energy-saving product suitable for industrial and urban water supply and drainage pumps. It can be used as a drainage or water supply pump for factories, cities, power stations, water conservancy, petroleum, engineering, and other industries. It can also be used for agricultural irrigation and other industries. |
