Description
Technical Parameters
Magnetic Drive Water Pump
The self-priming pump is a self-priming centrifugal pump with the advantages of compact structure, convenient operation, stable operation, easy maintenance, high efficiency, long life, and strong self-priming ability. The working principle of the self-priming pump is to pour water into the pump casing (or the pump casing itself has water) before starting. After starting, the impeller rotates at high speed, causing the water in the impeller groove to flow to the volute. At this time, a vacuum is formed at the water inlet, causing the water inlet check valve to open, and the air in the suction pipe enters the pump and reaches the outer edge through the impeller groove.
Product Parameter
| Customized support | OEM, ODM, OBM |
| Power Source | Electric |
| Brand Name | HNYB |
| Structure | Electric water pump |
| Application | Industrial Boilers, Industrial Utilities, Irrigation and Agriculture, Mining industry, Raw Water Intake |
| Place of Origin | Henan, China |
| Power | 1.5-110kw |
| Outlet Size | ≤100mm |
| Flow | 0.9-50m³/ H |
| Head | 3-50m |
| Material | Fluoroplastic/Alloy/Stainless steel |
Products Video
Product Features
Leak-free design: The magnetic pump adopts magnetic coupling drive technology, and the inner and outer rotors transmit torque through the magnetic field, thus avoiding the use of mechanical seals. This design effectively eliminates the problem of liquid leakage and ensures the safety and cleanliness of the operating environment.
High-efficiency transmission: Since there are no contact parts inside the pump body, this not only reduces wear but also improves energy transmission efficiency. High-pressure magnetic pumps can operate stably under high pressure and are suitable for handling high-viscosity and high-temperature liquids.
Low-noise operation: The non-contact design of the magnetic pump not only reduces wear but also significantly reduces the operating noise of the pump, providing a quieter working environment.
Product Certification
ISO 9001
ISO14001
ISO45001
CE Product Certification
EAC Product Certification
Verified Supplier
Our address
Zhaogang Industrial Park, Fengqiu, Xinxiang, Henan, China
WhatsApp Number
+86 158 3619 1545
sales@hnybpumps.com
FAQ
01. WHAT'S YOUR MOQ?
02. WHAT'S YOUR PAYMENT TERMS?
03. WHAT CERTIFICATES DO YOU HAVE?
04. ARE YOU A MANUFACTURING OR TRADING COMPANY?
05. CAN YOU DO OEM BRAND?
06. WHAT IS THE DELIVERY TIME?
Hot Tags: magnetic drive water pump, China magnetic drive water pump manufacturers
Product parameters
| Flow: | 0.9~50m³/h |
| Head: | 3~50m |
| Caliber: | ≤100mm |
| Power: | 1.5~110kw |
| Medium temperature: | 0~150℃ |
| Material: | Fluoroplastic/alloy/stainless steel, etc. |
| Scope of application: | It can transport most acid, alkali and salt solutions and is also exposed to the outdoor atmosphere, so it has good corrosion resistance. |
