High efficiency multistage centrifugal pump
Featuring CFD-optimized hydraulic design and an IE3 motor, they significantly reduce plant energy costs.
Maximum Efficiency Index (MEI) ≥ 0.7.
Description
Technical Parameters
Henan Yibeng Pump Industry Co., Ltd. is one of the leading manufacturers and suppliers of high efficiency multistage centrifugal pump in China. We have world-leading production equipment and strong manufacturing capabilities. Please rest assured to buy durable high efficiency multistage centrifugal pump at competitive price from our factory.
High efficiency multistage centrifugal pump
The HNYB high-efficiency multistage centrifugal pump is designed for industrial and municipal water treatment applications. It utilizes advanced CFD (Computational Fluid Dynamics) hydraulic geometry and optimized multi-stage impeller technology. This configuration minimizes internal hydraulic friction, achieving optimal volumetric output and significantly reducing daily operating energy consumption for plant utilities. It achieves maximum hydraulic efficiency, lower energy consumption, and reliable long-term operation.
It is widely used in boiler feedwater systems, mine drainage, industrial water conveyance, booster stations, irrigation projects, and municipal water supply networks. This series of pumps offers flow rates from 3.7 to 1350 cubic meters per hour and maximum heads up to 1800 meters.
Product Parameter
| Customized support | OEM, ODM, OBM |
| Power Source | Electric |
| Brand Name | HNYB |
| Structure | Multistage Pump |
| Application | Industrial Boilers, Industrial Utilities, Irrigation and Agriculture, Mining industry, Raw Water Intake |
| Place of Origin | Henan, China |
| Power | 3~1600kw |
| Outlet Size | ≤300mm |
| Flow | 3.7~1350m³/h |
| Head | 50~1800m |
| Material
|
Cast Iron / Ductile Iron / Cast Steel / Stainless Steel |
Products Video
Structural
Typical Applications
Industrial Water Supply
Reliable water transfer for manufacturing plants and industrial facilities.
Boiler Feed Systems
Stable high-pressure water supply for industrial boilers.
Mining Drainage
Mine dewatering and underground water removal systems.
Municipal Water Supply
Long-distance water transportation and pressure boosting stations.
Agricultural Irrigation
Large-scale irrigation and water distribution projects.
Water Treatment Plants
RO systems, filtration systems, and water processing facilities.
Technical Matrix & Energy Efficiency Ratings
| Engineering Indicator | Standard High-Efficiency Range | Premium Eco-Design Upgrades |
|---|---|---|
| Minimum Efficiency Index (MEI) | MEI ≥ 0.4 (Standard) / MEI ≥ 0.7 (Premium) | Exceeds standard EU eco-design directive limits |
| Flow Rate Capacity (Q) | 5 to 1,200 m³/h | Precision impeller trimming matching your exact Best Efficiency Point (BEP) |
| Total Dynamic Head (H) | 40 to 1,400 meters | Multi-stage staggered balance design minimizing internal recirculation |
| Matched Driving Motor | IE3 Premium Efficiency / IE4 Super Premium | Fully integrated VFD starter systems for smart pressure regulation |
| Impeller Manufacturing Process | Precision Investment Casting (Lost Wax) | Ultra-smooth surface finishes achieving minimal skin friction losses |
Product Features
Advanced Hydraulic Design: Optimized impeller and diffuser geometry reduces hydraulic losses and improves overall pump efficiency.
Lower Energy Consumption: High-efficiency hydraulic components help reduce energy consumption and long-term operating costs.
Wide Performance Range: Suitable for low-flow, high-head applications and large-capacity water delivery systems.
Stable Continuous Operation: Designed for harsh industrial environments requiring 24-hour operation.
Extra-Long Service Life: Heavy-duty shaft design, wear-resistant components, and an optimized balancing system enhance reliability.
IE3/IE4 High-Efficiency Motors: The performance of a high-efficiency pump casing depends on the motor that drives it. Our pumps are equipped with high-quality IE3 or ultra-high-efficiency IE4 motors. These heavy-duty motors feature IP55 protection and Class F insulation, operate at lower temperatures, consume less power per hour, and deliver a faster return on investment for plant upgrades.
Replaceable Wear Rings to Prevent Circulation Leakage: As pumps age, internal clearances increase, causing high-pressure fluid to flow back to the low-pressure suction side, thus reducing efficiency. Our pumps come with high-quality replaceable wear rings. These wear rings have tight mechanical tolerances to prevent internal circulation leakage, ensuring the pump always operates at its factory-set optimal efficiency point.
Certification
ISO 9001
ISO14001
ISO45001
CE Product Certification
EAC Product Certification
Verified Supplier
FAQ
01. WHAT'S YOUR MOQ?
02. WHAT'S YOUR PAYMENT TERMS?
03. WHAT CERTIFICATES DO YOU HAVE?
04. ARE YOU A MANUFACTURING OR TRADING COMPANY?
05. CAN YOU DO OEM BRAND?
06. WHAT IS THE DELIVERY TIME?
Hot Tags: high efficiency multistage centrifugal pump, China high efficiency multistage centrifugal pump manufacturers
Product parameters
| Flow range: | 3.7~1350m³/h |
| Head: | 50~1800m |
| Caliber: | ≤300mm |
| Power: | 3~1600kw |
| Medium temperature: | -20℃~150℃ (need to explain if it is higher than 80℃) |
| Material: | Cast iron/ductile iron/cast steel/stainless steel, etc. |
| Scope of application: | Transporting clean water or special liquids that do not contain or contain a small amount of solid particles, mainly used for industrial, mining and urban water supply and drainage, pressurized water supply for high-rise buildings, garden sprinkler irrigation, fire pressurization, long-distance water delivery, heating, bathrooms and other hot and cold water circulation pressurization and equipment supporting etc. |
