Screw Displacement Pump
abrasive, shear-sensitive and solids-laden fluids. Ideal for sludge, wastewater,
chemical processing, food production and industrial applications.
Description
Technical Parameters
Screw Displacement Pump
The HNYB Screw Displacement Pump is a positive displacement pump engineered for transferring viscous, abrasive, shear-sensitive, and solids-containing liquids with stable flow and minimal pulsation.
Unlike centrifugal pumps that rely on velocity and centrifugal force, screw displacement pumps move fluid through sealed cavities formed between a precision-machined rotor and stator. This operating principle ensures accurate flow control, excellent suction capability, and reliable performance regardless of system pressure. Screw displacement pumps maintain a nearly constant flow rate even when discharge pressure changes.
Widely used in wastewater treatment, chemical processing, oil and gas production, food manufacturing, paper mills, and mining operations, these pumps provide a dependable solution for handling difficult fluids that conventional centrifugal pumps struggle to transfer.
Product Parameter
| Parameter | Value |
|---|---|
| Flow Rate | 0.8 – 150 m³/h |
| Pressure | 0.6 – 1.2 MPa |
| Power | 0.75 – 37 kW |
| Outlet Size | ≤250 mm |
| Temperature | 0°C – 150°C |
| Material | Cast Iron / Ductile Iron / Cast Steel / SS304 / SS316 |
| Drive Type | Electric Motor / Gear Motor |
Products Video
Application Scenario:
- Environmental Protection: Industrial and domestic wastewater treatment, oily wastewater treatment, conveying of various sludge containing solid particles and short fibers, oil-water separation, and waste gas treatment.
- Petrochemicals: Conveying clean/heavy oils, acids, alkalis, and salt solutions; various viscous pastes and emulsions of chemical grouting materials; oil-water separation and waste oil recovery systems; polymer conveying.
- Exploration and Mining: Conveying drilling mud; mine water supply and drainage; mine dust collector water supply; mine tunnel wall mortar and concrete coating.
- Pharmaceuticals and Food: Conveying ointments, syrups, jams, fermentation liquids, honey, creams, starch pastes, toothpaste, etc.
- Shipbuilding: Bulch cleaning pumps, ship incinerator transfer pumps, oil-water separator matching pumps, conveying oily wastewater and other media from tanks.
Product Features
High Efficiency and Quiet Operation: Screw displacement pumps are renowned for their quiet operation, thanks to their minimal pulsation and internal contact. They maintain high efficiency across a wide range of pressures and viscosities. This is because the fluid flows axially with virtually no turbulence or backflow.
Self-Priming and Reversible Operation: These pumps are typically self-priming, meaning they can purge air and begin pumping without external water injection. They are also reversible, allowing bidirectional flow. This feature is particularly useful in systems requiring cleaning or drainage.
Low Maintenance Costs: Screw displacement pumps require minimal maintenance due to their few moving parts and low wear. The screw rotates smoothly with minimal clearance, reducing internal friction. Therefore, these pumps offer a long service life, even under harsh conditions.
Excellent Viscosity Handling: Capable of pumping low-viscosity liquids as well as highly viscous media up to extremely high viscosity ranges.
01
High efficiency and energy saving
Adhering to specialized production, we have uniquemethods for product model selection, mold making, and the casting process of hydraulic components.
02
Advanced process equipment
In order to ensure the assembly performance ofthe productsour company imported advanced parts cleaning equipment from abroad, and each part wascarefully deaned before the final assembly.
03
Unique structure
Install an O-shaped seayears ofg on the mating surface ofthe balance ringand the pump to prevent high-pressure water from entering the balance chamber, reduce balanceplate wear, and extend product service life.
04
Reasonable selection of materials
The material of the balance plate and balance ring can bemade of surfacing carbide, alloy steel or QT600Mn, alloy ductile cast iron according to different userneeds.
Product Certification
ISO 9001
ISO14001
ISO45001
CE Product Certification
EAC Product Certification
Verified Supplier
Our address
Zhaogang Industrial Park, Fengqiu, Xinxiang, Henan, China
WhatsApp Number
+86 158 3619 1545
sales@hnybpumps.com
FAQ
01. WHAT'S YOUR MOQ?
02. WHAT'S YOUR PAYMENT TERMS?
03. WHAT CERTIFICATES DO YOU HAVE?
04. ARE YOU A MANUFACTURING OR TRADING COMPANY?
05. CAN YOU DO OEM BRAND?
06. WHAT IS THE DELIVERY TIME?
Hot Tags: screw displacement pump, China screw displacement pump manufacturers
Products parameters
Flow rate: 0.8~150m³/h
Head: 0.6~1.2MPa
Caliber: ≤250mm
Power: 0.75~37kw
Medium temperature: 0~150℃
Material: cast iron/ductile iron/cast steel/stainless steel, etc.
